MRCOOL A/C Condenser 5 Ton 16 SEER R410A 60,000 BTU 208-230V/1Ph/60Hz

MRCOOL A/C Condenser 5 Ton 16 SEER R410A 60,000 BTU 208-230V/1Ph/60Hz

$2,156.00 USD
$2,556.00 USD $2,156.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Stay cool and save money with the MRCOOL 5 Ton Split System A/C Condenser. This 208-230 volt condenser, when paired with other MRCOOL products, promises a seasonal energy efficiency rating of up to 16 SEER. Beat the heat with its powerful cooling and enjoy lower utility bills year after year. Please note, this is not a heat pump.

  • CoolGuard total corrosion protection technology designed coil
  • Corner-mounted controls for easy service
  • Full metal louvered construction to protect the coil/ hail protection
  • Factory installed high pressure switch
  • Thread-on pressure switches for simple, quick replacement
  • 10 year limited warranty on compressor
  • Charged for 15 feet of line set
  • Fan orifice for smoother airflow and sound level reduction
  • Lanced fins for maximum heat transfer
  • Every coil factory tested for leak proof construction
  • All units ETL and ETLC approved and AHRI Certified
  • Internally protected against high temperature motor overload conditions

SEER

up to 16

MAX SEER

16

EER

11.7

CFM

1780-1800

TONNAGE

5

COOLING CAPACITY (BTU)

57000-58000

VOLTAGE (V)

208-230

PHASE

1

CYCLE

60

STAGE

Single

MAX FUSE BREAKER (A)

50

MIN CIRCUIT AMPACITY (A)

29.6

COLOR

Gray

COLOR FAMILY

Gray

RATED LOAD

22.2

MAX COVERAGE AREA

2500

REFRIGERANT TYPE

R-410A

REFRIGERANT VOLUME (OZ)

192

DECIBEL RATING (DBA)

80

INVERTER

No

MIN AMBIENT HEAT (F)

-20

LINESET INCLUDED

No

LINE SET LENGTH

15, 25, 35, 50

MAX LINESET LENGTH (FT)

50

LINESET FITTING TYPE

Sweat

LIQUID LINE SIZE

3/8

SUCTION LINE SIZE

7/8

COMPRESSOR MOTOR TYPE

Scroll

CONDENSER FAN MOTOR TYPE

Direct Drive

CONDENSER FAN MOTOR HP

1/3

CONDENSER FAN MOTOR RPM

825

METERING DEVICE

TXV

AUXILIARY HEATER INCLUDED

No

AUXILIARY HEATER AVAILABLE

Yes

AUXILIARY HEATER SIZES

7.5kw, 10kw, 15kw, 20kw

UL RECOGNIZED

No

UL LISTED

No

ETL LISTED

Yes

ETL CERTIFIED

No

LEED CERTIFIED

No

ENERGY STAR COMPLIANT

No

ENERGY STAR CERTIFIED

No

AHRI CERTIFIED

Yes

REGISTERED WARRANTY

10 year registered parts warranty

BASE WARRANTY

Standard 5 year limited parts warranty

REGISTERED PARTS WARRANTY

Registered 10 Year Parts Warranty

BASE PARTS WARRANTY

5 Year Parts Warranty

HAS BATTERIES

No

CONTAINS ELECTRONICS

Yes

CONTAINS CHEMICALS

Yes

CONTAINS AEROSOL

Yes

CONTAINS COMPRESSED GAS

Yes

PROPOSITION 65 WARNING

Yes

RESTRICTED STATES

No

NET DEPTH (IN)

43.00

NET HEIGHT (IN)

32.25

NET WIDTH (IN)

32.25

NET WEIGHT (LBS)

226.00

GROSS DEPTH (IN)

35.00

GROSS HEIGHT (IN)

43.50

GROSS WIDTH (IN)

34.50
