Goodman 5 Ton Heat Pump Package 13.4 SEER2, Two Stage, Horizontal, GPHH36031

The Goodman GPHH36031 is a 5-ton packaged heat pump system that offers reliable heating and cooling all year round for residential and light commercial settings. With a 13.4 SEER2 efficiency rating, R-32 refrigerant and a dual-stage scroll compressor, this horizontal discharge packaged unit offers great airflow and great indoor comfort. The Goodman GPHH36031 combines heat pump heating and cooling into one self-contained outdoor cabinet, making it a great option for buildings that need reliable indoor climate control without the need for separate indoor HVAC components.

Product Overview

The Goodman GPHH36031 includes the condenser, evaporator coil, compressor, and blower all in one. This integrated system allows for easy installation and service and offers cooling in the summer and heat pump heating in the winter. The unit is designed for horizontal airflow and can be installed on rooftops and below the ground, making it ideal for residential and light commercial as well as other light commercial buildings.

Quick Facts

• Model / SKU: GPHH36031
• System Type: Packaged Heat Pump System

• Heating Capacity: Approx. 54,000 BTU

• Compressor Type: Two-Stage Scroll Compressor

• SEER2 Rating: 13.4 SEER2

• Refrigerant: R-32

• Voltage: 208 / 230 Volt

• Phase: Single Phase

• Airflow Configuration: Horizontal Discharge

• Application: Residential & Light Commercial Heating and Cooling
• Dimensions (L × W × H):   34″ × 66″ × 38-1/2"

Capacity & Coverage

Thanks to its 5-ton cooling capacity, the Goodman GPHH36031 offers efficient climate control in medium-to-large houses and light commercial units. The system uses a heat pump with a heating capacity of 54,000 BTU to heat the house in cooler months and provide a cooling solution in hotter months.

Efficiency

This system provides 13.4 SEER2 efficiency, which means it uses little energy while offering reliable performance. To comply with modern environmental prerequisites for refrigerators. Goodman GPHH36031 uses an R-32 refrigerator, which improves heat transfer.

Construction & Design

The Goodman GPHH36031 includes a durable galvanized steel cabinet with a powder-coat finish designed for long-term outdoor use. Internal components such as the two-stage scroll compressor, multi-speed ECM blower motor, and aluminum coil construction support efficient airflow and reliable operation across changing climate conditions.

Installation & Application

Goodman GPHH36031 is a self-contained heat pump solution. Therefore, it is easy to install. All main HVAC components have already been housed in the outdoor unit. With horizontal discharge, it offers flexibility for placement for top-mounted and ground-mounted installations. It is ideal for residential, commercial and retrofitting HVAC solutions.

Noise & Comfort

The Goodman GPHH36031 has been made for comfort by neutralizing hot and cold spots by creating controlled steady airflow and temperature. With two-stage compressors, GPHH36031 is able to balance the season's extreme climate conditions by creating hot and cold control switches on demand and neutralizing the indoor areas.

FAQs

Q1: What refrigerant does the Goodman GPHH36031 use?
A: This system uses R-32 refrigerant.

Q2: What is the heating capacity of this unit?
A: The unit provides approximately 54,000 BTU heating capacity.

Q3: What electrical supply is required?
A: The system operates on 208–230 V single-phase power at 60 Hz.
